Panel Type | LCD |
Display Size | 2.4″ / 6.1 cm |
Screen Resolution | 1440 x 900 |
Image Controls | Anamorphic De-Squeeze, Check Field, Color Temperature Selection, False Color, Focus Peaking, H/V Delay, Histogram, Image Flip, OSD Flip, R/G/B/Chroma Only, Underscan, Waveform, Zebra |
Video I/O | 1 x BNC Input 1 x HDMI Input |
Power I/O | 1 x Unspecified 4-Pin (24 VDC) Input |
Other I/O | 1 x USB-A 2.0 Input |
Video Format | SDI (8-Bit) 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 1080PsF: 30/29.97/25/24/23.98 720p: 60/59.94/50 480i: 59.94 576i: 50 HDMI (8-Bit) UHD 4K: 30/25/24/23.98 DCI 4K: 24 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 1080PsF: 30/29.97/25/24/23.98 720p: 60/59.94/50 576p: 50 576i: 50 480p: 60/59.94/50 480i: 60/59.94/50Show More |
Diopter Correction | -3.0 to +8.0 |
Battery Type | 1 x LP-E6 |
Power Consumption | 5 W (Maximum) |
Mounting | 1 x NATO Rail 3 x 1/4″-20 Female 1 x Rosette |
Display
Color/Monochrome | Color |
Panel Type | LCD |
Display Size | 2.4″ / 6.1 cm |
Screen Resolution | 1440 x 900 |
Viewing Angle | Horizontal: 160° Vertical: 160° |
Touchscreen | No |
Maximum Brightness | 450 nits / cd/m2 |
Contrast Ratio | 1100:1 |
Bit Depth / Color Support | 8-Bit (16.7 Million Colors) |
Pixels Per Inch (ppi) | 728 ppi |
Image Controls | Anamorphic De-Squeeze, Check Field, Color Temperature Selection, False Color, Focus Peaking, H/V Delay, Histogram, Image Flip, OSD Flip, R/G/B/Chroma Only, Underscan, Waveform, Zebra |
Inputs / Outputs
Video I/O | 1 x BNC Input 1 x HDMI Input |
Power I/O | 1 x Unspecified 4-Pin (24 VDC) Input |
Other I/O | 1 x USB-A 2.0 Input |
Video Format | SDI (8-Bit) 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 1080PsF: 30/29.97/25/24/23.98 720p: 60/59.94/50 480i: 59.94 576i: 50 HDMI (8-Bit) UHD 4K: 30/25/24/23.98 DCI 4K: 24 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 1080PsF: 30/29.97/25/24/23.98 720p: 60/59.94/50 576p: 50 576i: 50 480p: 60/59.94/50 480i: 60/59.94/50 |
Optics
Diopter Correction | -3.0 to +8.0 |
Field of View | 178° |
Power
DC Input Power | 7 to 24 VDC |
Battery Type | 1 x LP-E6 |
Power Consumption | 5 W (Maximum) |
General
Mounting | 1 x NATO Rail 3 x 1/4″-20 Female 1 x Rosette |
